| Model | Unit | SD13 |
| Brand |
| GZMA |
| Operating weight (standard) | kg | 16000kgs |
| Engine |
| SC8D143G2B1 |
| Emission |
| China-II |
| Net power |
| 105kW |
| Rated revolution | rpm | 2400 |
| Number of cylinder bore×stroke |
| 6-114X135m |
| Displacement | L | 8.27 |
| Cooling system |
| air conditioner |
| Drive system |
| torque flow transmission |
| Gears |
| 3 gears forward and 3 gears backward |
| Max. theoretical traction force |
| 205.5kN |
| Torque converter |
| 3-element, single stage, 1-phase |
| Torque damper |
| Spring damping |
| Number of track shoe |
| 38 pcs/side |
| Number of carrier roller |
| 2 pcs/side |
| Number of track roller |
| 6pcs/side |
| Track shoe type |
| Single grouser |
| Track gauge |
| 1880mm |
| Fuel capacity |
| 280L |
| Engine oil capacity |
| 25L |
| Hydraulic oil tank |
| 112L |
| Blade type |
| Straight-tilt blade |
| Blade capacity |
| 3.15 m3 |
| Machine height |
| 2950mm |
| achine length (w/o draw bar) |
| 4492mm |
| Max. lifting height of blade |
| 930mm |
| Max. digging depth of blade |
| 545mm |
| Blade width |
| 3264mm |
| Blade height |
| 1140mm |
| Rear ripper |
| Three teeth |
