| Tractor Model | LTB904 |
| Drive Type | 4×4 |
| Overall Dimension L×W×H(mm) | 4080×1750×2880( top of safety frame) |
| Wheel base(mm) | 2080 |
| Front wheel tread(mm) | 1285 |
| Rear wheel tread(mm) | 1350、1450、1550
|
| Min. ground clearance(mm) | 370 |
| Min. operating weight(KG) | 2820 |
| Gearbox gears number | F12+R12 |
| Max. Forward Speed (Kw/h) | 32.26 |
| Hydraulic output numbers | two pairs两组 |
| Engine Brand | QUANCHAI全柴 |
| Engine Model | 4C6-90U32 |
| Engine Type | inline,water-cooled,four stroke,direct injection,t6urbocharged,four cylinders
|
| Engine Rated power (Kw) | 6.2 |
| Engine Rated speed(r/min) | 2400 |
| Front tires spec. | 8.3-24 |
| Rear tires spec. | 14.9-30 |
| Max. traction force (KN) | 20.727 |
| Max. lifting force(KN) | 31.40 |
| PTO Power(Kw) | 56.27 |
| PTO Type | Rear-mounted, Semi-independent type |
| PTO Speed (r/min) | 540/760 或or 540/1000 |
| PTO Shaft Size | 8splines，6splines as option |
| Steering type | Full hydraulic front wheels steering |
| Control type of ploughing depth | Height control & Flotation control |
| Suspension type/category | Rear-mounted three-point linkage, Category Ⅱ |
| Front/Rear Iron ballast as option | Front Max.112KG/ Rear Max.200KG as otion |
| Fuel Tank Capacity（L） | 90 |
